Pos. Name Piece Order no.
1 Cover 1 1010021
2 Pan-head screw M4x12 DIN 912 4 0912D012
3 Motor 1 on request
4 Pump 1.9 l 1 102103
5 Capacitor 12,5 µF 1 EK12220
6 Universal RC - link 1 EE0104
7 Connection cable with plug 1 EK32220
8 Screwed connection PG 13.5 1 EV0113
9 Valve 1 on request
10 Pan-head screw M6x45 DIN 912 4 0912F045
11 Pressure gauge 1 101004D
12 Screwed connection of pressure gauge 1 V042314
13 Mini hose 1 on request
14 Hose screwing 1 101008
15 Accumulator 1 101006
16 Ring for sealing 16x22.7x1.5 1 D16x22,7
17 Coupling box, flat packing 1 VMU14
18 Synthetic cap for VMU14 1 VKM14
19 Coupling plug, flat packing 1 VST14
20 Synthetic cap for VMST14 1 VKS14
21 Ring for sealing 16x22.7x1.5 2 D16x22,7
22 Screwed connection 2 V101024
23 O-ring 19x1,5 2 D19x1,5
24 Distributor box 1 on request
25 Pan-head screw M4x10 DIN 912 2 0912D010
26 Socket 2 EST0701
27 Seal, inside 1 1010024
28 Side part 1 1010022
29 Seal, outside 1 1010023
30 Pan-head tapping screw 3.5 x 20 4 7971C020
31 Valve lever 1 101013
32 Cylinder knob M10 1 101033
33 Bellows 1 101035
34 Plate "Release pressure" 1 SCHD-L
35 Hexagon nut M10 DIN 934 1 0934J
36 Pressure switch 1 ESEK103
37 Pan-head screw M4x25 DIN 84 2 0084D025
38 Angle for pressure switch 1 on request
39 Washer M4 DIN 125 1 0125D
40 Pan-head screw M 4x10 DIN 912 1 0912D010
41 Set screw M5x10 DIN 915 1 0915E010
42 Bolt 1 101038
43 Adjusting screw 1 101036
02.11.2011 Working instructions WIDOS 4900 Page 41 / 1 of 46
