Pos. Name Piece Art.-No.
1 Heating element H 4900, 230 V 1 H4900D
Heating plate new 1 HP4900D
Heating plate for change 1 HPT4900D
2 Temperature probe PT1000 1 H09082
3 Probe holder 1 235037
4 Toothedlock washer 14,5 DIN 6797 1 6797D
5 Oval-head screw M 4x8 DIN 7985 2 7985D006
6 Tapped bushing 2 HGEW-M6
7 Insulator plate 2 H0902
8 Spring washer M6 DIN 127B 2 0127F
9 Pan-head screw M 6x75 DIN 912 2 0912F075
10 Grip joining piece 1 H0909
11 Rocker switch, red lightet 1 H0903
12 Thermo regulator GD4 1 H0908230D
13 Window for grip case 1 H09071
14 Knob with slot 1 H09075D
15 Control lamp, green 1 H2105
16 Teflon-conical nipple for heating element 1 H09091
17 Oval-head screw C4,2x19 DIN 7981 3 7981D019
18 Heat sink with TRIAC BTA 216 1 H09081
19 Handle case 1 H0907
20 Lustre terminal 1 on request
21 Oval-head screw 2,9x13 DIN 7981 2 7981C013
22 Strain relief 1 EK3220
23 Pan-head screw M 4x70 DIN 912 3 0912D070
24 Grip 1 H0906
25 Antikink grommet 1 EKT08
26 Connecting cable with plug 1 EK3220
02.11.2011 Working instructions WIDOS 4900 Page 43 of 46
