Pos. Name Piece Art.-No.
1 Heat absorbing steel sheet 1 214528
2 Insertion for heating element 1 214523
3 Stirrup 1 214527
4 Fitting cab Ø20x2 2 J5401
5 Spacing bolt for heating element 2 214525
6 Spacing bolt for planer 2 216524
7 Foot-mounting 2 214521
8 Blind rivet 4x10 DIN 7337 8 7337D010
9 Hexagon bolt M 8x160 DIN 933 2 0933H180
10 Hexagon domed cap nuts 6AU M 8 DIN 1587 2 1587H
11 Washer M 8 DIN 125 2 0125H
12 Insertion for planer 1 214522
13 Fitting cap 40x30x2 4 J0203
02.11.2011 Working instructions WIDOS 4900 Page 45 of 46
