SA-IN Input Module
© 2010 Wieland Electric GmbH | BA000256 | 12/2012 (Rev. I)
33
Function
Input module in the samos system
Function display 11 green LEDs, 1 red LED
Controls 2 10-position switches
Terminals Plug-in terminals with screws / spring force
Max. number of modules / status in system 12 / slave on SBus
___________________________________________________________________________
Power circuitry (internal) Min. Typical Max.
Operating voltage U
B
, DC 19.2 V 24.0 V 30.0 V
Residual ripple V
SS
3.0 V
Rated power, DC
1.2 W
___________________________________________________________________________
Input circuit ( I1..I8 ) Min. Typical Max.
Input voltage, U
E
(HIGH) 13.0 V 30.0 V
(LOW)
–5.0 V 5.0 V
Input current, I
E
(HIGH) 2.4 mA 3.0 mA 3.8 V
(LOW)
–2.5 mA 2.1 mA
Cyclical peak input current, I
E,PEAK
15 mA
Input capacitance, C
IN
200 nF
Input resistance, R
IN
8 k
ON period*, t
E
70 ms
OFF period*, t
A
> t
AN
Break time of U
E
(HIGH) 1.0 ms
Break time period
20 ms
Synchronous time t
S
(Functions 3, 5) 1500 ms
___________________________________________________________________________
Output circuit (X1.. X8 ) Min. Typical Max.
Output voltage
18.0 V 30.0 V
Output current in sum
150 mA
Wire capacitance, C
L
1000 nF
Wire resistance, R
L
100 
Short-circuit behavior Absolutely short-circuit-proof
___________________________________________________________________________
Input test t
TI
, typ. t
TD
, typ. t
TP
, typ.
Test pulse width* t
TI
;Test duration**, t
TD
;
Test pulse period, t
TP
Functions 1, 2, 3, 4, 5, 8 12 ms 20 ms 40 ms
___________________________________________________________________________
Response times Min. Typical Max.
Response time*** t
AN
(normal operation)
Function 1
Functions 6, 7
Functions 2 (without safety mat), 3, 4, 5, 8
Function 2 (safety mat)
33 ms
16 ms
24 ms
42 ms
Technical data
SA-IN
* For the times see the
function diagrams at the
end of the table.
The sum of currents,
which are drained from
all input modules of one
system to supply external
sensors, may not exceed
600 mA!
* Signal changes are not
detected during the test
pulse.
** Signal changes from
HIGH to LOW are not
detected during the test.
For the times see the
function diagrams at the
end of the table.
*** The response time t
AN
is the time between the
output signal arriving at the
input terminals and the
semiconductor outputs of
the associated base
module actually being shut
down. The time is
independent of the
number of input modules
connected to the base
module.
