WIKA CPG1000 User Manual

14 WIKA operating instructions model CPG1000
11568047.02 08/2012 GB/D
GB
3. Specications
Approvals and certicates
CE conformity
EMC directive 2004/108/EC, EN 61326-1 emission (group 1, class B) and interference
immunity (Appendix A)
ATEX directive II 3G Ex nA IIB T6
CSA directive Class I, division 2, groups A, B, C, D
Certicate
Calibration 3.1 calibration certicate per DIN EN 10204
option: DKD/DAkkS calibration certicate
For further specications see WIKA data sheet CT10.01 and the order documentation.
For further important safety instructions for the operation in hazardous
areas see chapter 2.3 "Additional safety instructions for instruments per
ATEX".
Available measuring ranges and resolutions
Measuring ranges and factors part 1
Measuring range
in bar
0 ... 0.07 0 ... 1
-1 ... +1
0 ... 2
-1 ... +2
0 ... 7 0 ... 20 0 ... 35
Unit Conversion factor
psi 1 1.0000 15.000 30.000 100.00 300.00 500.00
bar 0.06894757 0.0689 1.0342 2.0684 6.8948 20.684 34.474
mbar 68.94757 68.948 1,034.2 2,068.4 6,894.8 20,684 34,474
kPa 6.894757 6.8948 103.42 206.84 689.48 2,068.4 3,447.4
MPa 0.00689476 0.0069 0.1034 0.2068 0.6895 2.0684 3.4474
kg/cm² 0.07030697 0.0703 1.0546 2.1092 7.0307 21.092 35.153
mmHg (0 °C) 51.71507 51.715 775.73 1,551.5 5,171.5 15,515 25,858
inHg (0 °C) 2.03603 2.0360 30.540 61.081 203.60 610.81 1,018.0
cmH
2
O (4 °C) 70.3089 70.309 1,054.6 2,109.3 7,030.9 21,093 35,154
cmH
2
O (20 °C) 70.4336 70.434 1,056.5 2,113.0 7,043.4 21,130 35,217
mmH
2
O (4 °C) 703.089 703.09 10,546 21,093 70,309 --
1)
--
1)
mmH
2
O (20 °C) 704.336 704.34 10,565 21,130 70,434 --
1)
--
1)
mH
2
O (4 °C) 0.703089 0.7031 10.546 21.093 70.309 210.93 351.54
mH
2
O (20 °C) 0.704336 0.7043 10.565 21.130 70.434 211.30 352.17
inH
2
O (4 °C) 27.68067 27.681 415.21 830.42 2,768.1 8,304.2 13,840
inH
2
O (20 °C) 27.72977 27.730 415.95 831.89 2,773.0 8,318.9 13,865
inH
2
O (60 °F) 27.70759 27.708 415.61 831.23 2,770.8 8,312.3 13,854
ftH
2
O (4 °C) 2.306726 2.3067 34.601 69.202 230.67 692.02 1,153.4
