WIKA S-20 User Manual

10 WIKA operating instructions pressure transmitter, model S-20
14043170.01 04/2013 GB/D/F/E
GB
3. Specications
Electrical connection maximum permissible temperature
Angular connector DIN 175301-803 A -30 ... +100 °C
Angular connector DIN 175301-803 C -30 ... +100 °C
Circular connector M12 x 1 (4-pin) -30 ... +100 °C
Circular connector M12 x 1 (4-pin, metallic) -40 ... +125 °C (cULus: +85 °C)
Bayonet connector (6-pin) -40 ... +125 °C
Field case -25 ... +100 °C
Heavy-duty connector -40 ... +125 °C
Cable outlet IP 67 -30 ... +100 °C
Cable outlet ½ NPT conduit -30 ... +100 °C (cULus: +90 °C)
Cable outlet IP 68 -30 ... +125 °C (cULus: +90 °C)
Cable outlet IP 68, FEP -40 ... +125 °C (cULus: +105 °C)
Cable outlet IP 69K -30 ... +125 °C (cULus: +90 °C)
Climate class
Storage: 1K3 (per EN 60721-3-1)
Transport: 2K2 (per EN 60721-3-2)
Operation: 4K4H (per EN 60721-3-4, without condensation or icing)
Vibration resistance (per IEC 60068-2-6)
20 g, 10 ... 2,000 Hz, (40 g, 10 ... 2,000 Hz for heavy-duty connector)
For instruments with cooling elements a limited vibration resistance applies 10 g (10 ... 2,000 Hz)
Continuous vibration resistance (per IEC 60068-2-6)
10 g
Shock resistance (per IEC 60068-2-27)
100 g, 6 ms (500 g, 1 ms for heavy-duty connector)
Free-fall test (following IEC 60721-3-2)
Individual packaging: 1.5 m
Multiple packaging: 0.5 m
PE bag: 0.5 m

WIKA S-20 Specifications

General

Accuracy	≤ 0.5 % of span
Output Signal	4 ... 20 mA, 0 ... 10 V, 0.5 ... 4.5 V ratiometric
Process Connection	G ¼ NPT, ¼ NPT
Electrical Connection	M12 x 1
Materials (wetted)	Stainless steel
Temperature Range	-40 ... +125 °C
Ingress Protection	IP65
Power Supply	10 ... 30 V DC
