11WIKA operating instructions pressure transmitter, model S-20

14043170.01 04/2013 GB/D/F/E

3. Specications

Vacuum tightness

Yes

Overpressure limit

The overpressure limit is based on the sensor element used. Depending on the selected process connection and

sealing, restrictions in overpressure safety can result. A higher overpressure limit will result in a higher temperature

error.

Measuring range < 10 bar/150 psi ≥ 10 bar/150 psi

3 times (standard) 2 times

(standard)

5 times 3 times

2) 3)

1) Restriction: max. 60 bar/870 psi with absolute pressure

2) Only possible for relative pressure measuring ranges ≤ 400 bar or 5,800 psi

3) Only possible for absolute pressure measuring ranges < 16 bar or 220 psi

Process connection Maximum overpressure limit

G ⅛ B 800 bar

G ¼ B, G ¼ B female, G ⅜ B 1,400 bar

G ½ B 1,800 bar (1.4404), 3,200 bar (1.4542)

G ¼ A, G ½ A, M14 x 1.5, M12 x 1.5 600 bar

M20 x 1.5 1,800 bar (1.4404)

3,300 bar (1.4542)

7/16-20 UNF BOSS 600 bar

7/16-20 UNF J514 sealing cone 74° 1,100 bar

9/16-18 UNF BOSS 600 bar

⅛ NPT 1,100 bar

¼ NPT, ¼ NPT female 1,500 bar

½ NPT 1,500 bar (1.4404), 2,800 bar (1.4542)

PT ¼ 1,600 bar

PT ½ 1,500 bar

PT ⅜ 1,400 bar

R ¼ 1,600 bar

R ½ 1,500 bar

R ⅜ 1,400 bar (1.4404), 2,840 bar (1.4542)

All process connections in combination with a cooling element have a maximum overpressure limit of 400 bar.
