Wilesco D100E - Page 40

40
Components in an overview:
amount
type
detail
1
generator, permanent excited, current
machine
1
generator bracket
1
bread board
170 contacts
1
switch
1
LED, red
5 mm
1
LED, orange
5 mm
2
LED, white, extra bright
5 mm
mind. 2500 mcd
1
flash-LED, red
5 mm
1
electrolytic
1000µ, 10 V (or
higher)
2
electrolytic
4700µ, 10 V (or
higher)
1
Diodes, Schottky
BAT 48
2
Crocodile clips
red, black
2
pins
5
resistor, carbon ¼ Watt
1, 10, 100 Ohm, 2x
1K
0,5m
wire, rot
0,6 mm
0,5m
wire, black
0,6 mm
Note:
It is recommended to follow the instructions and the order given in the
booklet. This facilitates the understanding and eases the mounting and
changes. Later on you can repeat the experiments in your own order of
choice.
Recommendation of the following order:
 read the instructions
 mount the experiments
 check the mounting
 prepare the components for the experiments
 start and run the steam engine
Only use the generator for the here designed purposes!
