Fig.3.24: Principle of the direction of the rotation and current direction
3.5 Mounting the generator
Components: generator with mounting support, pulley belt, generator
holders, screws
To mount the generator on the basic plate of the steam machine one uses a
two-piece compression fitting in combination with the generator mounting
support.
You can install the generator to almost all basic plates of the Wilesco steam
engine models.
Depending on the type of the steam engine model they produce rotations
from 1000-2000R/min at the axis of the flywheel.
Fig.3.26: Parts for mounting the generator, a) two-piece holder of the
generator, b) mounting support of the generator and adjusting screw
