Wilo Atmos PICO User Manual

16 Wilo SE 07/2019
en
• Pressing the button for the 6th time returns to
the basic setting (constant speed / characteristic
curve III).
LED display Control mode Pump curve
1 Constant speed
II
2 Constant speed
I
3 Variable differential
pressure
Δp-v
III
4 Variable differential
pressure
Δp-v
II
5 Variable differential
pressure
Δp-v
I
6 Constant speed
III
NOTE
All settings and displays are retained if the power
supply is interrupted.

Wilo Atmos PICO Specifications

General

Max Flow Rate	2.5 m³/h
Max Head	6 m
Protection Class	IP42
Insulation Class	F
Maximum Operating Pressure	10 bar
Voltage	230 V
Frequency	50 Hz
Connection Size	1 inch
Type	Circulation Pump
Application	Domestic Hot Water Circulation
Max Liquid Temperature	95°C
Weight	2.1 kg
