Wimius T7 - Page 6

Introductions
Projector Schematic
1. Remote receiver
2. Air intake
3. Adjustable foot
4. Focus lens
5. Power input
6. Input terminals
Back
Front
5 6
V ide o A udio -in A udio- out
P C R G B-
HD M I2 H DM I1
