Wimius T7 - Installation; Full Setting

Installation
Full Setting
Please install in reference to the instruction below.
Speaker L
Subwoofer
Speaker C
Screen
Speaker R
Seats
DVD
Amplier
Projector
Speaker LS Speaker RS
In order to get the best image quality, do not expose the projector
to sunshine or any other strong light source. Close the curtain and
dim the lights if you will use the projector in a bright room.
