WINCODE C342 - Media and Sensor Settings

C34 USER MANUAL
- 59 -
2) Media
Item
Description
Sensor-Label Sensor
Which sensor is using; Reflective and Transmissive
Sensor-Sensor Sensitivity
Low/Middle/High are selectable
Label-Label Type
Label with Gaps, Label with Black Line, and Continuous label are
selectable
Label-Paper Width
The user can enter the parameter. (default: 4 inches)
Label-Paper Length
The user can enter the parameter. (default: 3 inches)
Gap-Gap Length
The user can enter the parameter. (default: 0.4016 inches)
Gap-Length after Gap
The user can enter the parameter.
Label with Black Line-Black Line
Thickness
The user can enter the parameter. (default: 0.4016 inches)
(Only when it is loaded the label with black line.)
Label with Black Line-Length after
Black Line
The user can enter the parameter.
(Only when it is loaded the label with black line.)
Sensor Value- Reflective
The user can enter the parameter.
Sensor Value-Transmissive
The user can enter the parameter.
3)Others
Item
Description
Characters
The user can select the parameter.
RS-232
Can be set when the port is RS-232.
Internet Connection
The default is DHCP, if select manual, the user can adjust the
parameter,
Bluetooth
The user can enter the name and PIN code.
