Maintenance9403−3/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
8/ 9
Tool 94315 Pre-tensioning jack for elastic bolt to top end bearing
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder 10 Control pin
5 Back-up ring
O-ring
Sealing ring
6
94315−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
2
3
5
6
MAX. STROKE 8 MM
94315−KJ
7
1
4
WCH00981
10
9
8
2013
Hydraulic Pre-tensioning Jacks: Storing, Servicing and Maintenance
