WinGD WARTSILA RT-flex58T-E - Page 476

Maintenance9403−5/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
10/ 37
94141
94141A
1
2
Support
for removal and fitting
of main bearing shells
X = 870 mm
Ground plates
X = ∅ 100 mm
Y = 50 mm
010.399/02
X
017.848/08
X
Y
94142−L
94142−R
1
1
Working platform
X = 1532 mm
Grid left side
Grid right side
009.947/02
X
94142−L
94142−R
94143 2 Working supports
X = 570−680 mm
009.323/01
X
94145
94145−KJ
1
1
Pre-tensioning jack
for foundation bolts and engine stays,
including a metal box
X = 150 mm
K
it with back-up and O-rings
for pre-tensioning J
ack
X
010.400/02
2014-01
Standard Tools
