Winget 4B2000 - Page 106

DRIVE AXLE, Newage, braked B - 8
Item Part no Description Qty
- 30156A05 * AXLE, assembly 1
(stamped 200RF14S321 on axle casing)
- 30156A05 + AXLE, assembly 1
(stamped 200RFD14S321 on axle casing)
- 30156A09 + AXLE, assembly 1
(stamped 200RF14S3210 on axle casing)
Note:
Items marked
*
should only be used on axles
marked 200RF14S321 on axle casing.
Items marked
+
should only be used on axles
marked 200RFD14S321 or 200RF14S3210 on
axle casing.
All other items are common.
1 30156A0101 CASING, axle 1
2 30156A0102 PIN, dowel 4
3 30156A0103 / 1530214 ANNULUS 2
3 30156A0202 1530215 / ANNULUS 2
4 30156A0104 / 1530214 PLATE, brake spacer 2
4 30156A0206 1530215 / PLATE, brake spacer 2
5 30156A0105 PLATE, brake, fixed 4
6 30156A0106 DISC, brake 4
7 30156A0107 PISTON, brake 2
8 30156A0108 SEAL, piston (one set) 1
9 30156A0109 NUT, bearing adjusting 2
10 30156A0110 PLATE, bearing adjusting nut 2
11 30156A0111 HOUSING, bearing
2
12 11S03C SCREW, set 12
12A 17S04 WASHER, spring 12
14 30156A0112 PIN, dowel 2
15 182S20 VALVE, brake bleed 2
15A 30347A0218 ADAPTOR, brake pipe 4
15B 30156A0155 SEAL, bonded 4
16 11S04D SCREW, set 6
16A 59S03 NUT, nyloc 6
18 30156A0114 / March 86 * SUN GEAR, 22 teeth spline 2
18 30156A0907 March 86 / + SUN GEAR, 25 teeth spline 2
V601140 / issue 02 0800 continued >
Axle serial no
