Every 50 operating hours, or
weekly
Check transfer gearbox oil level
Clean the area surrounding the filler/level
plug (Y) before removing it.
Check and top-up through the filler/level
plug hole (Y) until the oil is level with the
bottom of that hole.
For the correct type and grade of oil, see
“Specifications”.
Every 1000 operating hours
Change transfer gearbox oil
Place a suitable container beneath the
drain plug (Z).
Drain oil by removing the plug (Z) .(Do not
lose its sealing washer)
Replace drain plug with its sealing
washer.
Fill with oil at filler/level plug (Y) to the
correct level. Replace filler/level plug with
its sealing washer.
For the correct type and grade of oil, see
“Specifications”.
SERVICE 3.11
TRANSFER BOX
