Every 50 operating hours, or
weekly
WARNING Always use lubricants of the
grade specified.
Always lubricate and service
BEFORE work commences,
and WITHIN the periods
specified.
Grease points
Clean nipples BEFORE and
AFTER greasing. Apply the
grease gun until clean grease
appears.
Location of grease points
A Tipping rams (2 on each ram)
[No grease points on Rotating
or High discharge skip tipping
rams]
B Skip pivots (2)
C Propeller shaft (3)
D Brake pedal pivot (2)
E Clutch pedal pivot (2)
F Accelerator pivot (2)
G Front/rear chassis centre
pivot (2)
H Rear axle centre pivot (2)
I Handbrake cable (1)
J Gearbox clutch shaft pivot (1
each side of gearbox bell-
housing)
# Clean and lubricate all
linkages not fitted with a
grease nipple.
SERVICE 3.19
GREASING
