HUB & AXLE SHAFT B - 10B
Newage 212 series drive axle, (non braked)
Item Part no Description Qty
29 30082A0407 HUB 1
30 30156A0122 STUD, wheel 5
31 30082A0408 BEARING 1
32 30082A0409 BEARING 1
33 30082A0222 SPACER 1
34 30347A0201 LOCKWASHER 1
35 30156A0112 DOWEL, spring 2
36 30082A0410 SEAL, oil 1
37 8S04B BOLT 8
38
………………...
NUT, wheel (see "Wheels", page B-1)
….
39 30082A0411 LOCKNUT 1
47 30082A0421 SHAFT, axle (1475mm) 2
49 30082A0422 COVER, seal, wheel hub 2
V601140 /July '02
Axle serial no
