GEARBOX (with Newage axle) C - 1
Item Part no Serial no Description Qty
$ From gearbox batch no. B1238.
When replacing layshaft 30101A0223 on gearboxes prior to batch no B1238,
layshaft assembly 30101A0268 should be ordered.
This replaces the previous layshaft 30101A0223 and bush 30101A0244.
(Gearbox oil capacity becomes 2 litres - previously .85 litres).
From gearbox serial no. 0155335 (Apr 1993)
Needle roller bearing (item 52) changed from an imperial to a metric dimension.
This change also affects the Layshaft (item 28) and Casing (item 74).
See Layshaft Kit (item 28)
- 30101A03 / Jun-86
GEARBOX, assembly,
(with straight gear lever) 1
- 30101A02 / Jun-86
GEARBOX, assembly,
(with straight gear lever) 1
- 30101A09 JUN 86/ GEARBOX, assembly
(with cranked gear lever) 1
1 30101A0201 KNOB, gear lever 1
2 95S03 NUT, locking
3 20097A07 / Jun-86
LEVER, gear, straight,
1
3 20097A06 / Jun-86
LEVER, gear, straight,
1
3 30101A0901 JUN 86/ LEVER, gear, cranked 1
4 30101A0203 CAP, gear lever 1
5 30101A0204 COVER, gear lever 1
6 30101A0205 SPRING, gear lever 1
7 30101A0206 PLATE, gear lever retaining 1
8 28S05E BOLT 1
9 30101A0207 WASHER, tab 1
10 30101A0208 WASHER 1
11 30101A0209 RING, snap 1
12 88S06E BEARING, mainshaft, rear 1
13 30101A0211 GEAR, output 1
14 30101A0212 SPACER, output gear 1
15 30101A0213 WASHER, reverse pinion shaft 1
16 102S04 NUT, slotted 1
17 44S02C PIN, split 1
18 30218A0206 CIRCLIP 1
V601140 / issue 02 0800 continued >
