BRAKING SYSTEM, (From serial number 1093)
D - 7A
Newage front axle braking only
Item Part no Serial no Description Qty
1
MASTER CYLINDER (see page D-10)
1
2 267S05 WASHER, flat 2
3 8S03C BOLT 2
4 59S12 NUT, self-locking, 'Nyloc' 2
5 320S01E 1093 / HOSE, master cylinder to front axle 1
6 29S07 HOSE, nylon, one metre long 1
7 110S01A ADAPTOR, nozzle, straight 1
7A 135S01 ADAPTOR, nozzle, swept 135 deg.
(Used with hydraulic rotating skips) 1
8 53S01W 1093 / HOSE, axle bridge 1
9 120S01 CAP, blanking 1
10 165S04 CLIP, nylon hose 2
11 V2003515 1093 / ADAPTOR, male/male 5
12 298S03 1093 / SEAL, bonded 5
13 129S01A 1093 / ADAPTOR, elbow 1
182S20 BLEED SCREW, supplied with axle
(not illustrated) 1
V601140 / July '02
