CHARGING & STARTING CIRCUIT F - 1A
Lister TS2 & TR2
Item Part no Serial no Description Qty
NOTE: Up to February 1991, engines were fitted with ‘Syncro’
charging systems (see illustration
).
From February 1991, engines were fitted with ‘Nicsa’ charging
systems (see illustration
).
The two systems are not interchangable.
Ascertain whether the engine is fitted with ‘Syncro’ or ‘Nicsa’
charging system before ordering parts.
Engines fitted with ‘Syncro’ charging system
(illustration A)
1 - # STATOR, flywheel alternator 1
2 - # SWITCH, key start 1
6 - # INDICATOR, battery charge 1
9 - # RECTIFIER / REGULATOR 1
10 109S08 BATTERY 1
11 - # STARTER MOTOR 1
13 - # LIGHT, warning 1
- 30231A09 LOOM, wiring 1
# Items supplied with engine.
For engine parts, see “Engine Parts Catalogue”.
Engines fitted with ‘Nicsa’ charging system
(illustration B)
1 - # STATOR, flywheel alternator 1
2 - # SWITCH, key start 1
9 - # REGULATOR 1
10 109S08 BATTERY 1
11 - # STARTER MOTOR 1
13 - # LIGHT, warning 1
- 30231A11 LOOM, wiring 1
# Items supplied with engine.
For engine parts, see “Engine Parts Catalogue”.
V601140 / issue 02 0800
