CHARGING & STARTING CIRCUIT F - 2
Petter PH2
Item Part no Serial no Description Qty
- 30231A03 WIRING HARNESS 1
1 109S08 BATTERY 1
2 10989A01 CABLE, positive 1
3 10990A01 CABLE, negative 1
- 180S01 TIE, cable AR
12 10961A01 LEAD, extension 1
13 10961A0101 PLUG 2
Items supplied with engine
4 - SWITCH, start 1
5 - AMMETER 1
6 - STARTER, c/w solenoid 1
7 - ALTERNATOR 1
8 - SENSOR, temperature 1
9 - SWITCH, pressure 1
The following items are not illustrated
- 30178A02 GUARD, alternator 1
- 10382A02 BRACKET, alternator guard 1
- 10382A03 BRACKET, alternator guard 1
- 63S02A SCREW, guard fixing 4
- 17S03 WASHER, spring, guard fixing 4
- 12S02 WASHER, flat, guard fixing 4
V6001140 / issue 01 0891
