Winget 4B2000 - Page 63

CHASSIS, Hydraulic rotating skip A - 1A
Item Part no Serial no Description Qty
1 V2004770 CHASSIS, front, rotating skip 1
2 10640A03 RING, bearing 1
3 11S05E SCREW, set 8
4 267S07 WASHER, flat 16
5 61S05 NUT, “Binx”, self-locking 8
6 54S08J PIN, roll 4
10 V2004145 FRAME, rotating 1
11 11S05E SCREW, set 6
11A 11S05F
SCREW, set (not illustrated)
4
12 267S07 WASHER, flat 16
13 61S05 NUT, “Binx”, self-locking 10
15 V2004234 SCREW, skip stop 2
16 7S08 NUT 2
17 17S11 WASHER, spring 2
20 30113A06 RAM, tipping 1
21 10720A02 Pin, ram base pivot 2
22 11S03M SCREW, set 2
23 61S03 NUT, “Binx”, self-locking 2
25 131S01 NIPPLE, grease 2
26 176S01 CAP, grease nipple 2
30 30287A03 RAM, rotating 2
31 6S07MM BOLT, (rotating ram eye) 2
32 10S06 WASHER, flat 6
33 107S18 NUT, “Nyloc” self-locking 2
35 6S07V BOLT, (rotating ram base) 2
36 10S06 WASHER, flat 6
37 107S18 NUT, “Nyloc”, self-locking 2
40 V2004494 COVER 2
41 11S03B SCREW,set 4
42 17S04 WASHER, spring 4
43 267S05 WASHER, flat 4
55 V2004212 SAFETY SUPPORT, tip ram 1
56 902S02 PIN, lynch, c\w chain 2
57 V2004217 PIN 2
58 106209000
SEAL, strip, (2 meters)
1
59 176S01 CAP, grease nipple
V601140 / July '02
