SKIP, Manual rotating A - 4
Item Part no Serial no Description Qty
40312A01 SKIP, 508mm mouth, asembly
40312A02 SKIP, 1067mm mouth, asembly
1 40217A01 SKIP, 508mm mouth 1
1 40217A02 SKIP, 1067mm mouth 1
2 40116A03 FRAME, skip 1
2A 131S01 NIPPLE, grease 2
2B 176S01 CAP, grease nipple 2
3 10640A02 RING, slewing turntable 1
3A 176S01 CAP, grease nipple 4
3B
NIPPLE, grease 4
4 8S05D BOLT 4
5 267S07 WASHER, flat 8
6 59S04 NUT, nylon insert 4
7 10833A04 PLATE, front mount 1
8 30306A01 PLATE, rear mount 1
9 8S05E BOLT 4
10 267S07 WASHER, flat 8
11 59S04 NUT, nylon insert 4
12 10522A04 PIN, skip pivot 2
13 11S04C SCREW, set 2
14 7S04 NUT 2
15 17S05 WASHER, spring 2
16 10919A01 PIN, ram upper pivot 1
17 11S04C SCREW, set 1
18 7S04 NUT 1
19 17S05 WASHER, spring 1
20 10720A02 PIN, ram lower pivot 1
21 55S07Q PIN, tension 1
22
RAM, hyd (see Hydraulics Section) 1
23 31S02K HOSE, ram to bulkhead 2
24 40296A03 CATCH, skip locking 1
25 8S05H BOLT 1
25A 59S04 NUT, 'Nyloc' self-locking 1
25B 267S07 WASHER, flat 1
26 11S02H SCREW, set 1
26A 267S04 WASHER, flat 3
27 187S08JJ CLAMP, hose 1 pair
28 C173D SPRING, skip catch 2
29 7S02 NUT 1
30 61S02 NUT, 'Binx' self locking 1
31 11S07P SCREW, set 2
32 7S07 NUT 2
V2003111
TIE, nylon (not illustrated)
2
V2003253
TIE, nylon (not illustrated)
1
V601140 / issue 02 0800
