7-13
SECTION 7 –
PLUMBING
WATER HEATER BYPASS AND
ANTIFREEZE SIPHON VALVES
Your coach is equipped with a Water Heater
Bypass valve and an Antifreeze Siphon
(Winterization) valve for winterizing waterlines
using RV antifreeze.
Turn the handle as shown to either bypass or
flow mode.
Refer to the “Water System Drain Valve
Locations” chart at the end of this section for
locations on your model.
Waterline Drain Valves
-Typical installation shown
Water Tank Drain Valve
-Typical installation shown
Leave bypass valve handle in NORMAL
FLOW position if draining water and
blowing out waterlines. Place in BYPASS
position ONLY when using antifreeze
solution in waterlines.
