WATER SYSTEM DRAIN VALVE LOCATIONS
Model System Drain Valve Locations
Models 27K
& 30C
Waterlines
• Model 27K - One (1) valve beneath bed (lift bed board to
access) and two (2) valves beneath galley sink (remove
bottom panel to access).
Open exterior shower knobs and lay shower head on ground.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in the
city waterline.
• Model 30C - Two (2) valves below wardrobe (remove drawer
to access).
Open exterior shower knobs and lay shower head on ground.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in the
city waterline.
Water Tank
• Model 27K - One (1) valve beneath bed (lift bed board to
access).
• Model 30C - One (1) valve in rear driver side compartment.
Water Heater
• Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• Model 27K - One (1) valve beneath galley sink (remove front
panel to access).
• Model 30C - One (1) valve beneath galley sink (remove panel
to access).
Winterization
(Antifreeze) Valve
• Model 27K - One (1) valve beneath bed (lift bed board to
access).
• Model 30C - One (1) valve beneath bed (remove panel on
front side of bed base to access).
