Advanced Menu
Power on (only for MCR42, not MCR41)
Allow to enable both the receivers:
Only receiver 1 (Rx1), only receiver (Rx2) or (Rx1 + Rx2).
Edit RX (MCR42 has the same menu for RX1 and RX2)
Selecting this sub-menu most of RX1 or RX2 setups are
configurable.
Selecting Name, it’s possible to edit the name of the receiver
(12 characters). The number of visible characters in the
parameter Name depends on the type of characters used
(uppercase or lowercase characters).
Select current group and channel.
Group name and channel frequency are displayed on the
right.
If the specific group/channel is not locked, then can be
edited in this menu.
This menu allows to disable the RF squelch (OFF) or to setup
the desired squelch level in dBµV (note 0 dBµV is equal to -
107 dBm).
