ACCESSORIES AND PARTS
TOP FEED OPTIONS & SLOT IN
MCR42 has 4 main audio sources:
 Audio Line 1&2
 AES3 (audio 1&2, 48kHz 24bit)
 PTT (push to talk) 1&2
 Headphone (left/right)
Top feed can bring on top on a mini-XLR 5M connector two balanced audio called line1 and line2.
MCR42-Exx can then be in factory configure to connect on top (line 1 & 2) the audio source you
need.
Line 1 & 2 to XLR
MCR42-ECL: PTT Line 1 & Audio Line 2
MCR42-ELC: Audio Line 1 & PTT Line 2
MCR42-EC2: PTT Line 1 & 2
MCR42-EL2: Audio Line 1 & 2
CAM50-42
Line 1 to XLR
Line 2 to XLR
CAM50-41
CAM50-3
MCR42-Exx
IKEGAMI/PANASONIC +
Flange for Six Pack of PSC
IKEGAMI/PANASONIC
GRASS VALLEY
SONY
SLOT-IN KIT
SLK42-IK
Standard:
6dB attenuated
SLK42-IK-0
Without
attenuation
SLK42-SX
Standard:
20dB attenuated
Without
attenuation
SLK42-SX-0
SLK42-PH
Standard:
10dB attenuated
SLK42-IK-PSC
Standard:
6dB attenuated
