Advanced
Headphones
Volume
23÷5dB (step 1 dB)
Balance
L+12÷L+1 / 0 / R+1÷R+12
RX mix Rx1+20÷Rx1+1 / 0 / Rx2+1÷Rx2+20
Rx
RX1(L+R)/RX2(L+R)/RX1+RX2(L+R)/RX1(L);RX2(R)/RX1(R);RX2(L)
Signal LINE/TSQ>LINE
Power On RX1+RX2/ /RX1
Edit RX1/RX2
Name (12 characters)
Gr-Ch
GR: 0÷39
CH: 0÷59
Frequency
(step 25kHz)
N: 470.000÷700.000
M: 566.000÷798.000
Squelch OFF- 0/3/6/9/12/15/18/21/24/28/32/36/40/46 dBµV
Expander ENR Wis/ENC Wis/ENR-1.2/ENC-1.2
Tone Squelch
Tone Squelch OFF/ON/ADV
Config OFF TSQ OFF c LINE c COM
Config ON TSQ ON c LINE c COM
Config ADV
TSQ ADV
PTT Rel . c LINE c COM
PTT psh. c LINE c COM
Audio out
LINE max lev
MIC max lev
-8 ÷ +12 dBu (step 1dB)
-30 ÷ -10 dBu (step 1dB)
AES3 max lev
-30÷0 dBFS (step 1dB)
COM max lev -18÷+12 dBu (step 1dB)
LINE max lev
-18 ÷ +12 dBu (step 1dB)
Sign. Phase
0° / 180°
Scan
Cal. tone
OFF / 0dB / -18dB
LINE mode
AES-3 / Analog
Fast ch sel
By name / By Ch/Gr
Display
LED
Full / Alarm /OFF
Contrast
0÷5
Low Timeout
5÷60 sec (step 5 sec)
Off timeout
10÷120 sec (step 10 sec) / OFF
Sync
Only MCR42 (not MCR41)
Only with BPA42-PTT
Preset parameters
Only for Slot-in
BPA42HPN
Only for
HW rev ≥ 21
Only for
HW rev < 21
