WiT WT53R-485 - Overview; Parameter

WT53R-485 Manual v23-0720 | www.wit-motion.com | support@wit-motion.com
4
1 Overview
⚫ With voltage stabilization circuit, the working voltage is 5V~36V.
⚫ Black metal shell design, waterproof, high working stability.
⚫ High precision laser ranging sensor and optical filter. Effectively filter out
optical interference.
⚫ Set the alarm distance, if the measurement distance is less than the set
value, the voltage output of the alarm pin changes.
2 Parameter
Parameter
Specification
➢ Voltage
5V-36V
➢ Current
<38mA
➢ Size
23.2mm x69mm
0.913" x 2.717"
➢ Fixed Hole
Spacing 16mm, hole radius 1mm
Spacing 0.630", hole radius 0.039"
➢ Acquisition Rate
20Hz
➢ Measuring Distance
40mm-4000mm (4000mm without optical cover)
1.575"-157.480" (157.480"without optical cover)
➢ Interface
TTL
➢ Baud Rate
Supports 2400-921600, default 115200
➢ Ranging Error
±20mm ±0.787"
