User Manual WMF8000S
Care | Manual cleaning
4.5.3 Drip tray cleaning
Scalding hazard
• The drip trays may contain hot liquids.
• If the cup table drip tray is not properly
engaged, such as after cleaning, there is aburn
hazard due to hot liquids.
> Move the drip trays carefully.
> Replace carefully so that no water accidentally
drips down.
> Always make sure the cup table drip tray is
seated correctly.
 Release the lock at the bottom right of the cup table
drip tray[1]
 Remove the cup table drip tray[1]
 Remove the drip tray[2]
 Thoroughly clean both drip trays
 Rinse the drip trays with clear drinking water
 Dry off the drip trays and replace them
4.5.4 Clean the housing
• There is ahazard of causing scratches or scores.
> Do not clean with scouring powders or the like.
> Do not use any sharp cleaners or implements.
> Use soft cloths for cleaning.
For cleaning metal cover parts (matte surface) we
recommend WMFPurargan® cleaner.
4.5.5 Beneath the coffee machine
 Remove and clean the catch pan
 Wipe beneath the coffee machine with adamp cloth
CAUTION
Observe the Safety chapter
w starting on page 63
1
2
IMPORTANT
Observe the Warranty chapter
w starting on page 71
