User Manual WMF8000S
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
Rated voltage 220–240V 380–415V
Nominal power rating 3.4–3.8kW 6,0–7,0kW
Power supply 220–240V
50/60Hz (1/N/PE)
380–415V
50/60Hz (3/N/PE)
On-site fuse 1x 16A 3x 16A
Coffee bean hopper large approx. 1,150g per load **
Coffee bean hopper small approx. 730g per load **
Powder hopper (optional) * approx. 1,200g per load
Illumination LED class 1
External dimensions Width 390mm
Height 744mm (with bean hopper and lock)
Depth 590mm (598mm with small drip tray edge)
Weight empty approx. 76kg
(3grinders, 1mixer, 1milk)
Continuous sound pressure
level(Lpa)
< 70dB(A) ***
We reserve the right to make technical modifications.
* Only with optional powder hopper
** The capacity depends on the size of the coffee beans.
*** A-evaluated sound pressure level Lpa (slow) and Lpa (impulses) at operating personnel workplace is under
70dB(A) in any working mode.
Conditions for usage and installation
Necessary on-site preparatory work for electricity, water
and drainage connections at the customer‘s premises are
to be arranged by the machine owner/operator. The work
must be carried out by authorised installation technicians
in compliance with general, country-specific and local
regulations. The WMFService engineers may only connect
the coffee machine to existing prepared connection
points. WMFService is neither authorised nor responsible
for carrying out any on-site installation work prior to
connection. The potential equalization terminal is installed
by WMFService if needed.
