GMZ-E Operating manual Page 12 of 31 B0668
3.5.4 Level control optical/electrical
Switching voltage AC max. 400 VAC
max. 6 A
Switching voltage DC max. 400 VDC
max. 3 A
Electrical connection screw connection 2x (M20x1,5)
Protection class DIN EN 60529 IP66
Switching function positively driven NC contact
When connecting inductive or capacitive loads, the relevant suppressor
circuits (diode, RC element, varistor) need to be provided for!
