CGB-75 / CGB-100
6. Layout
Quick-action air vent valve
Gas fan
Heatingwaterheat
exchangers
Condensate trap
Gas combination valve
Heatingreturn
Gas supply pipe
Flue gas temperature limiter
Combustion chamber casing
Return sensor
Combustion chamber
cover temperature limiter
Flue
Heatingow
Burner
Flow sensor
Temperature limiter
Flow
Intake pipe
Flue gas test point
Ventilation air test point
Gas:air mixing chamber
Flash trap
Displacement device
Water pressure switch
Gas restrictor
Monitoring electrode
Ignition electrode
Non-return valve
