Cooling
How to gain access to the condensing units
Loosen and remove all screws on the roof of the unit. Remove
and put aside the roof panel.
Loosen and remove all screws on the front two access panels.
Remove the front panel.
Rotate and slide the two side covers off the unit. The covers
will slide out of the from latches on the side of the unit and can
then be set to one side
CAUTION
The discharge line will be hot when the unit has
been running. This is indicated by a label. The
unit should be allowed to cool before accessing.
Possible Hot Discharge Pipe
