SETUP & OPERATION
Planning / thicknessing
3
3-6 EGdoc072921
 The thicknessing depth is adjusted with the crank (J). The set thickness can be read on the
scale (K). Thicknessing depth can be adjust from 0,3 mm to 4 mm. The maximum depth can
be set for the material width not bigger than 160mm. Always measure material and adjust the
height before thicknessing.
See figure 3-4.
FIG. 3-4 MP160
Bottom Table
Height Scale (K)
Bottom Table Height
Adjustment Crank (J)
