Woods RD6000 User Manual

35PN-52886 (4/97)
RD6000, RD7200 & RD8400 MAIN FRAME ASSEMBLY
Ref Part No
No
No Used Description
8 33661 2 Category 1 mounting pin with nut
and lockwasher
9 ---------- -- CW Spindle assembly (see pages
38 & 39)
10 31615 1 V-Belt (used on RD6000 only) -- o r --
10 18879 1 V-Belt (used on RD7200 only) -- o r --
10 53418 1 V-Belt (used on RD8400 only)
11 53567 1 Belt guide, 8 GA formed
12 64555 1 Flat idler, 5.5” Dia.
13 55331 2 Offset link (for RD6000 only) -- o r --
13 19578 2 Offset link (for RD7200 only) -- o r --
13 52873 2 Offset link (for RD8400 only)
14 19579 2 Offset link, .38 x 2.00 x 25.88
15 19605 1 U-Link, .38 x 2.5 x 7.13
16 52893 1 PTO Hanger bracket
17A 55340 1 Right belt shield, RD6000 (if
RD6000 model decal is required,
also order #55338) -- o r --
17A 53539 1 Right belt shield, RD7200 (if
RD7200 model decal is required,
also order #53553) -- o r --
17A 52874 1 Right belt shield, RD8400 (if
RD8400 model decal is required,
also order #52876) -- o r --
17B 55340 1 Left belt shield, RD6000 -- o r --
17B 53539 1 Left belt shield, RD7200 -- o r --
17B 52875 1 Left belt shield, RD8400
18 29792 1 1/4 x 1/4 x 1 -1/4 HT Key
19 65197 1 12.4 PD Sheave, Offset 1, B 1.25
20 53534 1 Gearbox stand
21 53593 1 1:1.92 Gearbox (see page 36)
22 51849 1 Counter cone shield
23 40551 1 Drive assembly, two-lobe, complete
1240, 29.9 x 41.8 (see page 40 for
detail) -- o r --
23 ---------- 1 Drive assembly, Tri-lobe (see page
37 for repair parts only)
24 67131 1 Extension spring .177 x 1.22 x 9.88
25 53595 1 RD6000 & RD7200 Idler and
bearing 5.0 OD x .51 ID
25 64555 1 RD8400 Flat idler, 5.5” Dia.
26 67288 1 Idler arm assembly (includes
bushing, item #66)
27 55344 1 RD6000 Complete decal set -- o r --
27 53589 1 RD7200 Complete decal set -- o r --
27 52889 1 RD8400 Complete decal set
28 53590 1 French safety decal set
29 53591 1 English safety decal set
30 18824 2 Hitch plate
HARDWARE
Ref Part
No
No Description
40 35139 .050 x .75 External retainer ring
Ref Part
No
No Description
41 12296 * 1/4--28 Straight grease fitting 15/32 long
42 4378 * 5/16 Standard flat washer
43 39254 8mm x 1.25P x 16mm Hex head cap
screw GR8.8
44 62153 Whiz bolt, .375--16 x 1 flanged
45 855 * 1/2 Lockwasher
46 24537 1/2 x 1-3/8 x 3/8 Flat washer (used on
RD6000 & RD7200) -- o r --
46 22166 1/2 x 1 x 1/4 Flat washer (used on
RD8400)
47 33677 1/2 x 1-9/16 x 10GA Washer
48 31983 .50 x .88 x 18GA Shim washer
49 64814 1/2 Schedule 40 x 2.75 pipe
50 6100 * 1/2 NC x 1 -1/4 Hex head cap screw
GR5
51 24576 1/2 NC x 1-3/4 Hex head cap screw
GR5
52 1517 5/8 x 1-3/8 x 7 GA Flat washer
53 639 * 1/2 NC x 2-1/2 Hex head cap screw
GR5
54 29561 1/2 NC x 4-3/4 Hex head cap screw
GR5
55 23479 1/2 x 5 Hex head cap screw GR5
56 11900 * 1/2 NC Flanged hex locknut
57 29368 1/2 x 3/4 x 3-3/8 Sleeve (for HD tire)
-- o r -- -- o r --
57 19749 1/2 x 3/4 x 4-1/16 Sleeve (for pneumatic
tire)
58 53598 .51 x .67 x .36 Flanged sleeve (RD8400
only)
59 19025 5/8 NC Flanged head locknut
60 22060 5/8 x 1 x 1/4 Felt seal
61 484 5/8 x 1 x 7/16 HT Sleeve
62 1791 5/8 x 1 x 9/16 HT Sleeve
63 19024 5/8 x 1-3/4 Flanged hex head cap screw
64 34473 5/8 NC x 3 Hex head cap screw GR5
65 35145 3/4 x 1 x 1 Oilite bushing
66 24741 3/4 x 2 x 16GA Flat washer
67 30007 * 7/8 NF Hex nut
68 30008 * 7/8 Lockwasher
69 33647 1” Schedule 40 x .75 pipe (used on
RD6000 & RD7200) -- o r --
69 52854 1-1/4” Schedule 40 x .75 pipe (used on
RD8400)
70 65129 1” Schedule 40 x .50 pipe (used on
RD6000 & RD7200) -- o r --
70 52853 1-1/4” Schedule 40 x .50 pipe (used on
RD8400)
71 65130 1” Schedule 40 x 1.00 pipe (used on
RD6000 & RD7200) -- o r --
71 52855 1-1/4” Schedule 40 x 1.00 pipe (used on
RD8400)
* Obtain Locally
(Rev. 9/1/99)
