EGCP-2 Engine Generator Control Package Manual 26174
86 Woodward
Engine Control
Preglow Time
 Time of preglow allowed prior to engine crank cycle.
 Maintained through engine cranking.
 Resets after every crank attempt.
Crank Time
 Maximum Allowable Time for Engine Cranking.
Crank Cutout
 Engine rpm level where crank command is canceled.
Crank Delay
 Time between Engine Crank Attempts.
 This Delay is started when in the Spindown mode and the speed of the
generator set has dropped below 50 rpm. Cannot restart engine until this
time has expired.
Crank Repeats
 Number of times EGCP-2 will repeat its attempt to start the engine.
Cranking attempts will equal the value of Crank Repeats +1.
Crank Fail
 Alarm Set Point.
 Activates when the Number of Crank Repeats is depleted.
Idle Speed
 If the Relay #12 output is configured for Idle/Rated switch, this value will set
the speed at which the Idle/Rated Time begins.
 Value should be approx. 10% less than the actual idle speed of the
generator set.
Idle Time
 The delay in seconds the EGCP-2 waits once the Idle/Rated Speed set
point is exceeded. Once the Idle/Rated Time is passed, the EGCP-2 will
energize the #12 Discrete Output (if the Relay #12 output is configured for
the idle/rated function).
Cooldown Time
 Time allowed for cooldown once engine achieves a stop cycle.
 Must exceed Cooldown Limit (see next display) before activated.
Cooldown Limit
 kVA set point at which, when exceeded, will cause the engine to go to a
cooldown during the next stop cycle.
