Settings in the service menu
Greenstar 8000 Style – 6720883864 (2019/02)
50
7.2.2 Benchmark and Info menu
Table 17 Benchmark menu
Table 18 Info menu
Menu item Comment/restriction
Actual temp. Flow temperature in °C
DHW flow rate Hot water flow rate in l/min
Hot water temp.Outlet temperature in °C
Menu item Comment/restriction
Current status
Current fault Tab. 24, page 68
Fault history
Boiler
Mx.heat.outp % Max. heating output in %, Setting value in > Settings > Heating > Mx.heat.outp %
Mx.heat.outp kW Max. heating output in kW
Actual temp. Flow temperature in °C
Set flow temp. Setting value of the flow temperature
Low-loss hdr.tmp Only if installed. Momentary flow temperature in low loss header in °C
Heating mod. Burner modulation (heating) in %
Act. burner mod.
Burner output Current burner output in kW
Ionisation current Current ionisation current in μA
Pump mod. Actual system pump modulation in %
Outside temp. Current outside temperature in °C
HC1 pump Current status on/off
Burner starts Number of burner starts since commissioning
Hours run Elapsed time of the system since commissioning
System pressure Current system pressure in bar
Hot water
Max. outp.(kW) Max. hot water output in kW
DHW flow rate Current hot water flow rate in l/min
DHW act. temp. Actual hot water temperature in °C
Hot water temp. Current water temperature in °C
DHW set temp. Setting value of the hot water temperature
Refilling settings
System pressure Current system pressure in bar
No. of refills Number of automatic fillings since last reset
Last refill dur. Duration of last refill
Refilling active Automatic filling on
System
Contr.device ver. Software version of the control unit
Progr. unit ver. Software version of the control unit
Code plug no. Coding plug number
Code plug ver. Coding plug version
Key Type of installed key, e.g. "Connect-Key"
Solar
Collector temp. Collector temperature
Cyl.temp.bottom Cylinder temperature at bottom
Collector pump Collector pump
Solar fault Current faults
