Greenstar 8000 Style – 6720883864 (2019/02)
3.8 Product overview
Fig. 3 Product overview Combi boilers, combustion cover removed
[1] Plate heat exchanger
[2] KEY accessory housing slot (wireless Gateway)
[3] Condensate trap
[4] Data plate 1
[5] Hot water temperature sensor
[6] Pressure sensor
[7] Pressure gauge
[8] Venturi (sealed)
[9] Schrader Valve
[10] Fan
[11] Expansion vessel
[12] Heating flow
0010023231-001
15
2
14
12
11
9
10
8
1
25
24
5
13
6
17
18
19
20
21
22
23
27
28
30
4
31
29
7
32
16
3
26
