Inspection and maintenance
59
Greenstar 8000 Style – 6720883864 (2019/02)
▶ Remove the cleaning access cover [1] and seal [2].
Fig. 82 Access cover removal
▶ Using the cleaning blade, working from the bottom to the top, to
loosen any deposits in the heat exchanger.
Fig. 83 Cleaning blade
▶ Using the brush, clean the heat exchanger from top to bottom.
Fig. 84 Cleaning brush
▶ Use the handle of the brush to remove debris from the condensate
tray.
It is possible to rinse any remaining debris from the heat exchanger
either through the access point or alternatively through the top of the
heat exchanger when the burner is removed.
▶ Pour water into the heat exchanger to rinse the debris through to the
suitable container below the outlet to the siphon.
Fig. 85 Pour water into the heat exchanger
0010023710-001
1
2
0010023693-001
0 010 007 128-001
2
0010023695-001
