Electrical connections
y Cut cable grommet to diameter of cable.
Fig. 26
y Feed cable through cable grommet and connect the
mains supply cable, see fig. 27.
y Secure cable in cable grommet by means of cable
grip.
Fig. 27
4.2 Connecting TR2 Room thermostat
The TR2 should be connected to terminals 3, 4 and F
beneath the Textdisplay, page 8, fig. 4, item 422.
4.3 Mains Voltage external controls
connections
Fig. 28
0
1
2
3
4
5
E
6 720 610 332-12.1R
13-14
10-12
8-9
5-7
L
N
N
LL
R
S
S
4130-14.1R
230 V R
oom Thermostat Connections
Ns
Ls
LR
ST8
Ns
Ls
L
R
ST8
Remove Link
Neutral
Liv
e
Swit
ched Liv
e
Neutr
al
Live
Swit
ched Live
Motor
230 V Pr
ogrammer Connections
230 V r
oom thermos
t
at and
Programmer Connections
Ns
Ls
LR
ST8
Neutral
Live
Neutr
al
Live
Swit
ched Liv
e
Motor
Swit
ched Liv
e
Series
connection
to be made
safe
NOTE: Only double insulated controls not requiring an earth can be used
