WorkPro WTS 905/DY - Parts Identification

10
USER MANUAL FOR WTS TOWERS
PARTS IDENTIFICATION
Figure 24.
1
Support stabilizer legs carrier
11
Steel carrier
2
Steel cable
12
Base wheel
3
Top boost reinforcement
13
Pin horn
4
Red knob mast security system
14
Frontal leg
5
Strut reinforcement mast support
15
Steel carrier
6
Winch
16
Leveler screw
7
Tower mast
17
Leveler brace
8
Steel reinforcement strut
18
Leveler knob
9
Red knob base security system
19
Forks
10
Tower base
20
Leg carrier knob
