Page #17 background image
17
Cordless Lawn Mower WG730E WG730E.X
5. Mower is
abnormally
noisy and
vibrates.
A. Release Operating Bail to turn
mower off. Remove safety key
and batteries. Turn mower on
side and check blade to ensure it
has not been bent or damaged.
If blade is damaged, replace
with a replacement blade. If the
underside of the deck is damaged
return mower to an Authorized
service center.
B. If there is no visible damage
to the blade and the mower still
vibrates: Release Operating Bail to
turn mower off, Remove safety key
and batteries, and remove blade.
Rotate blade 180 degrees and
retighten. If mower still vibrates,
return the mower to an authorized
service center.
6. Battery
charger LED’s
not on.
A. Check plug connection.
B. Replace charger.
7. Battery
charger LED
does not flip to
green.
A. Battery needs to be diagnosed.
Take to authorized service center.
8. Mower not
picking up
clippings with
the Grass
Collection Bag.
A. Remove mulch plate when
bagging.
B. Chute clogged. Release
Operating Bail to turn mower off.
Remove safety key and batteries.
Clear chute of grass clippings.
C. Too much cut grass. Raise
cutting height of wheels to
shorten length of the cut.
D. Bag full. Empty bag more often.
9. When
mulching there
are clippings
visible.
A. Too much cut grass. Raise
cutting height of wheels to
shorten length of the cut. Do
not cut off more than 1/3 of total
length.
B. Check blade for sharpness.
Always keep blade sharp.
10. Low or
diminished
run-time after
many uses
A. Return to Authorized Service
location - may need new battery.
11. The battery
charger LED
flashes red
and the battery
can’t be
charged.
A. The battery overheats after
continuous use. Remove battery
from the charger and allow it to
cool to 42°C or less.
10. DECLARATION OF
CONFORMITY
We,
Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
On behalf of Positec declare that the product
Description Worx Cordless Lawn Mower
Type WG730E WG730E.X (7- designation of
machinery, representative of Cordless Lawn
Mower)
Function mowing grass
Complies with the following Directives,
2006/42/EC, 2014/30/EU
2011/65/EU&(EU)2015/863
2000/14/EC amended by 2005/88/EC
2000/14/EC amended by 2005/88/EC
Conformity assessment procedure as per Annex VI.
Measured Sound Power Level 94.9 dB(A)
Declared Guaranteed Sound Power Level 96 dB(A)
The notified body involved
Name: Intertek, Deutschland GmbH (notified
body 0905)
Address: Stangenstraße 1, 70771 LEINFELDEN-
ECHTERDINGEN
Standards conform to,
EN 60335-1, EN 60335-2-77, EN 62233, EN ISO 3744,
EN 55014-1, EN 55014-2
The person authorized to compile the technical file,
Name: Marcel Filz
Address Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
2021/11/12
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

Other manuals for Worx WG730E

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Worx WG730E and is the answer not in the manual?

Worx WG730E Specifications

General IconGeneral
TypePush lawn mower
Cutting width300 mm
Grass catcherYes
Product colorBlack, Orange
Number of wheels4 wheel(s)
Mulching function-
Maximum cutting height70 mm
Minimum cutting height30 mm
Grass collecting volume30 L
Number of height positions3
Power sourceBattery
Battery voltage20 V
Battery capacity4 Ah
