Worx WX420 User Manual

Mini-circular saw WX420
8
1. ON/OFF SWITCH
2. SOFT GRIP HANDLE
3. LARGE L SPANNER/ALLEN KEY
4. SMALL L SPANNER/ALLEN KEY
5. LASER ON-OFF SWITCH
6. LOCK OFF SWITCH
7. DUST EXTRACTION OUTLET
8. DEPTH OF CUT ADJUSTMENT AND LOCK LEVER
9. BASE PLATE
10. SAW BLADE
11. PARALLEL GUIDE FIXTURE
12. BLADE ALIGNMENT INDICATOR
13. PARALLEL GUIDE CLAMPING SCREW
14. PROTECTIVE BLADE GUARD
15. LASER GUIDE
16. BATTERY STORAGE COVER
17. SPINDLE CLAMPING SCREW (See Fig. C)
18. BLADE CLAMPING WASHER (See Fig. C)
19. PARALLEL GUIDE (See Fig. D)
20. VACUUM ADAPTER (See Fig. E)
21. PLASTIC BASE PLATE COVER (See Fig. F1)
22. LASER BATTERIES (TWO) (See Fig. J3)
23. DEPTH OF CUT INDICATOR

Worx WX420 Specifications

General

Product color	Black, Orange
Protection class	II
Blade diameter	85 mm
Idle speed (max)	3500 RPM
Sound power level	91 dB
Cutting depth (90º)	27 mm
Sound pressure level	80 dB
Sound level uncertainty	3 dB
Saw blade included	Yes
Diamond disc	-
Uncertainty K	1.5 m/s²
Vibration emission	4.24 m/s²
Input power	400 W
Power source	AC
AC input voltage	230-240 V
AC input frequency	50 Hz

Weight and Dimensions

Weight	1500 g
