11
Cordless Reciprocating Saw EN
Helping to minimise your vibration and noise
exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration and noise accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.
ACCESSORIES
WX500 WX500.9
Wood cutting
blade
1 1
Metal cutting
blade
1 1
Battery pack
(WA3551.1)
1 /
Charger
(WA3880)
1 /
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing The Battery Pack See Fig. A1
Charging The Battery Pack
NOTE:
• The battery is shipped uncharged.
It must be fully charged before the
first use.
• More details can be found in
charger’s manual.
See Fig. A2
Installing The Battery Pack See Fig. A3
Angle adjustment of pivoting blade
foot
See Fig. B1
Depth of cut adjustment
See Fig. B2,
B3
Assembling the Hook and Bit Clip
See Fig. B1,
B2, B3, B4
Tool-Less Blade Fitting
NOTE:
• Before inserting the blade, turn the
tool-free blade clamp lever counter-
clockwise to its maximized angle and
hold it.
• The blade should be inserted to the
end while fitting.
• After the blade is fit well, the tool-
free blade clamp lever will return to
original position automatically.
See Fig. C1,
C2
OPERATION
Safety On/Off Switch See Fig. D
Variable Speed Control See Fig. E
Wood Cutting See Fig. F
Metal Cutting See Fig. G
Plastic / Aluminum Cutting See Fig. H
Flush Cutting See Fig. I
Pocket Cutting (Soft Materials Only) See Fig. J
NOTE:
Blades for steel/ Plastic / Aluminum are not supplied.
They are sold separately.
WORKING HINTS FOR
YOUR CORDLESS
RECIPROCATING SAW
If your power tool becomes too hot, run no-load
for 2-3 minutes to cool the motor. Avoid prolonged
usage at very low speeds.
Always use a blade suited to the material and
material thickness to be cut.
Always ensure the work-piece is firmly held or
clamped to prevent movement.
Any movement of the material may affect the quality
of the cut. The blade cuts on the upward stroke and
may chip the uppermost surface or edges of your
work piece when cutting, ensure your uppermost
surface is a non-visible surface when your work is
finished.
To Next Page
