BladeRunner
®
X2 EN
9
1. SWITCH WITH SAFETY KEY
2. STABILIZER BRACKET
3. BLADE STORAGE
4. MITER GAUGE
5. TABLE INSERT
6. GUARD KNOB
7. GUARD
8. VACUUM PORT
9. GUARD ARM
10. GUARD ARM CLAMP KNOB
11. RIP FENCE
12. FENCE SLOT
13. MITER SLOT
14. BLADE RELEASE
15. VACUUM ADAPTER (See Fig. K)
16. BOLT (See Fig. A1)
17. GUARD ARM ASSEMBLY KNOB (See Fig. A1)
18. BLADE (See Fig. B2)
19. BLADE HOLDER (See Fig. O)
