WPG P1HV1102DC3 - Page 10

P1-02DC3: #35122 Rev 2.2/12-218
3.3)
3D 3E
Make sure
hook has
restraining latch
(circled).
Attach the hoisting
hook to the lift point
(fig. 3D).
Use rigging (fig. 3E)
as needed to make
sure the hook does
not interfere with the
load.
Only use rigging rated for Maximum Load Capacity
plus Lifter Weight.
3.4) Use the hoisting equipment to remove the lifter from the shipping container. Avoid
damaging the vacuum pads
.
4B4A
4)
4C 4D
Connect the electrical
connectors (figs. 4A-B
and figs. 4C-D).
Install the 9-volt battery
fo
r the notification buzzer
as directed in “N
OTIFICATION BUZZER BATTERY REPLACEMENT”.
5)
5A
Remove the pad covers (fig. 5A) and save them for future use.
6) Perform tests as required under “T
ESTING”.
ASSEMBLY
