Designed for use with hoisting equipment, P1-02DC3 lifters support loads using vacuum and manipulate
loads using manual 180° rotation and manual 90° motions.
Model Number P110C02DC3 P110T02DC3 P1HV1102DC3 P111L02DC3 P11216L02DC3
Vacuum Pads:
1
1...... Available with other rubber compounds for special purposes (see www.wpg.com).
(2 each, standard rubber)
10" [25 cm]
nom. diameter,
concave
(Model G0750)
10" [25 cm]
nom. diameter
,
w/replaceable ring
(Model VPFS10T
2
2...... Standard with replaceable sealing rings for rough or textured surfaces (see “REPLACEMENT PARTS”).
)
10" [25 cm]
nom. diameter,
lipped
(Model HV11)
11" [28 cm]
nom. diameter,
lip
ped
(Model G3370)
12" x 16"
[31 cm x 41 cm]
nom. diimensions,
lip
ped
(Model RF1216)
Pad Spread:
(to outer edges)
23" x 10"
[59 cm x 25 cm]
25" x 11¾"
[64 cm x 30 cm]
24" x 11"
[61 cm x 28 cm]
25" x 12"
[64 cm x 30 cm]
25½" x 16½"
[65 cm x 42cm]
Maximum Load
Capacity
3
3...... The Maximum Load Capacity is rated at a vacuum of 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces with a friction coefficient of 1. Pad
compound, load rigidity, strength, surface conditions, overhang, angle, center of gravity and temperature can also affect the lifting capacity. A “qualified
person” should evaluate the effective lifting capacity for each use (see definition under “Rated Load Test”).
-------------------------------------- (standard and European ratings) -------------------------------------------
Standard Rating — Per-Pad
150 lbs [68 kg] 150 lbs [68 kg] 150 lbs [68 kg] 175 lbs [80 kg] N/A
Standard Rating — Total
300 lbs [135 kg] 300 lbs [135 kg] 300 lbs [135 kg] 350 lbs [160 kg] N/A
150 lbs [68 kg]
300 lbs [135 kg]
Lifter
Weight
-------------------------------------- 85 lbs [39 kg] -------------------------------------------
95 lbs [43 kg]
Power System 12 volts DC, 5.5 amps
Battery Capacity 7 amp-hours
Rotation
Capability
Manual, 180°, with latching at each ¼ turn (when required)
Tilt
Capability
Manual, 90°, with automatic locking in vertical position
Product
Options
Available with Remote Control System – FCC, CE and ICC certified.
See separate instructions about other options.
Operating
Elevation
Up to 6,000' [1,828 m]
Operating
Temperatures
32° — 104° F [0° — 40° C]
Service Life
20,000 lifting cycles, when used
and maintained as intended
4
4...... Vacuum pads, filter elements and other wear-out items are excluded.
Software Version
Intelli-Grip
®
7.6
ASME Standard BTH-1 Design Category "B", Service Class "0"
Troubleshooting Guide
5
5...... To view this guide, click the link at right. Additionally, you can search for your lifter's Model Number at www.wpg.com and select the “Troubleshooting” link
on the product page.
TST-021_DC3_REV_2018-023
Rev 2.2/12-21 P1-02DC3: #351223
SPECIFICATIONS
On construction sites, a secondary positive holding device(eg, load sling)
is required to achieve the Standard Ratings for the lifters above.
